TPC Superb Vac Wet Ring Vacuum System for Reliable Dental Evacuation

TPC Superb Vac Wet Ring Vacuum System for Reliable Dental Evacuation

Special Order: Ships in 2–4 weeks

SKU 22918002
$2,299.99
$2,299.99
$2,299.99
Model: WV3

Fast, secure delivery – Door-to-door service in SoCal.

Expert tech support – Installation consultation available.

30‑day money‑back guarantee – Easy returns & full refunds.

TPC Superb Vac Wet Ring Vacuum System, Durable aluminum-bronze construction, offers a quiet operation for small to medium size dental practices. 50/60 Hz, Stainless steel impeller, 2 3/8" air exhaust connection size. Computer balanced, sealed bearings in motor, 20x2 Amp circuit breaker. Easy to clean filter. Unique water recycling to save up to 80% water. This system represents a reliable, long-term infrastructure upgrade for any clinic prioritizing infection control and clinical excellence.

Please Note: This is a pre-order item. It will be shipped within approximately two weeks after the order is placed.

Features

  • High Power Ring Blower provides strong and stable suction to ensure continuous running, stable vacuum output sufficient to support multiple operatories simultaneously.
  • Copper Impellers ensure stable performance and longer running.
  • Unique Water Recycle Device saves 75%-80% water. Low energy consumption with environmentally friendly operation.
  • Built-in Water & Air Separator reduces noise level to ensure quiet and silent operation, efficient air-liquid separation to protect the pump and prolong service life.
  • Space-saving, Integrated Design for simplified installation and maintenance, quiet, vibration-free operation ideal for patient-sensitive environments.

        Specifications

        SKU Model Item details
        22918002 WV3 TPC WV3 Superb Vac Wet Ring Vacuum, Single Head, 1 x 1.2 HP Motor, 3 User (115V/60HZ)
        22918003 WV3-2 TPC WV3-2 Superb Vac Wet Ring Vacuum, Single Head, 1 x 1.2 HP Motor, 3 User (230V/60HZ)
        22918004 WV3R TPC WV3R Superb Vac Wet Ring Vacuum, WV3 (110V) w/ Water Recycler
        22918005 WV5 TPC WV5 Superb Vac Wet Ring Vacuum, Single Head, 1 x 2.0 HP Motor, 5 User (230V/60HZ)
        22918006 WV5R TPC WV5R Superb Vac Wet Ring Vacuum, WV5 (230V/60HZ) w/ Water Recycler
        22918007 WV6 TPC WV6 Superb Vac Wet Ring Vacuum, Twin Head, 2 x 1.2 HP Motors, 6 User, w A/W Separator (230V/60HZ)
        22918008 WV6R TPC WV6R Superb Vac Wet Ring Vacuum, Twin Head, 2 x 1.2 HP Motors, 6 User, w/Recycler
        22918009 WV10 TPC WV10 Superb Vac Wet Ring Vacuum, Twin Head, 2 x 2.0 HP Motors, 10 User, w A/W Separator (230V/60HZ)
        22918010 WV10R TPC WV10R Superb Vac Wet Ring Vacuum, Twin Head, 2 x 2.0 HP Motors, 10 User, w/Recycler



         Model WV3/WV3R (Single) WV5/WV5R (Single) WV6/WV6R (Twin) WV10/WV10R (Twin)
        Model Water consumption w/o Water Recycling 4L/min 4L/min 6L/min 6L/min
        Water consumption with TPC Water Recycling 0.8L/min 0.8L/min 1.0L/min 1.0L/min
        Suction Rate 900L/min 1500L/min 1800L/min 3000L/min
        Noise Level dB(A) 58 58 65 65
        Horsepower 1.2HP 2HP 2.4HP 4HP
        Max. Users 3 sets 5 sets 6 sets 10 sets
        Current (A) 8A 13A 8A×2 13A×2
        Circuit Breaker (A) 20A 20A 20A×2 20A×2
        Inlet Connection Size 3/4” 3/4” 1” 1”
        Drain Connection Size 32mm 32mm 32mm 32mm
        City Water Connection Size 8mm 8mm 8mm 8mm
        Air Exhaust Connection Size 60mm 60mm 60mm 60mm
        Inlet Water Pressure (PSI) Above 10 PSI or 0.7 bar Above 10 PSI or 0.7 bar Above 10 PSI or 0.7 bar Above 10 PSI or 0.7 bar
        Product Size (L × W × H mm) 420×360×460 420×360×460 720×430×460 720×430×460

        Warranty & Installation

        • One-Year Warranty
        • Installation Services: Professional installation services are available in Southern California. Please contact our service team at service@jmudental.com for availability, service details, and pricing information.

        How to Choose the Right TPC Superb Vac Model

        Choosing the correct central vacuum system for your dental practice is essential for reliable performance, efficient operation, and long-term satisfaction. To help us recommend the most suitable TPC Superb Vac model for your specific needs, please take a moment to review the key factors below.

        We recommend gathering the following information before placing your order:

        1. Clinic Scale & Usage Demand

        • How many dental chairs are in your practice?
        • How many chairs may be used at the same time?

        Why this matters: The total number of chairs, especially the simultaneous usage rate, directly determines the required vacuum flow rate (cfm/L/min) and motor power. A system that is too small will result in weak suction; an oversized system may waste energy.

        2. Installation Type

        • Is this a new installation or a replacement of an existing vacuum?

        Why this matters: New installations require more comprehensive planning for piping, electrical, and water connections. Replacements can often utilize existing plumbing and wiring, making the process simpler. For replacement projects, please also provide:

        3. Existing Equipment Reference (for replacements only)

        • Please send us a photo of the current vacuum unit and its nameplate (rating label).

        Why this matters: The nameplate clearly shows the existing unit's voltage, phase, power, and flow rate — giving us a direct reference to match or upgrade your system without guesswork.

        4. Power Supply Compatibility

        • What is the available power supply at the installation location? (Voltage and Phase)

        Why this matters: TPC Superb Vac systems are available in multiple electrical configurations (e.g., 230V / 460V, single-phase / twin-phase). Confirming this upfront ensures you receive a model that is electrically compatible, avoiding costly rewiring or delays.

        5. Utility Connections

        • Are water supply and drain connections available at the installation location?

        Why this matters: As a wet ring (liquid ring) vacuum system, the TPC Superb Vac requires a steady water supply for pump sealing and cooling, as well as a drain line for wastewater discharge. Pre-existing connections simplify installation significantly.

        6. Site & Logistics Information

        • What is the ZIP code of the installation location?

        Why this matters: Your ZIP code helps us consider local shipping logistics, delivery timelines, door-to-door available and, if applicable, any regional electrical or plumbing code requirements.

        7. Visual Reference (Highly Recommended)

        “If possible, please also send us a few photos of the current vacuum and the installation area. If you are unsure about any of the technical details, photos are perfectly fine — we will help review them for you.”

        Why this matters: A picture is worth a thousand words. Photos of the existing setup, utility connections, and available space allow our technical team to verify compatibility and provide accurate recommendations without back-and-forth emails.

        What is the difference between the TPC Superb Vac and other dental vacuum systems?
        The TPC Superb Vac is a wet ring (liquid ring) vacuum system, specifically engineered for dental central suction. Unlike dry vane pumps, it uses a water seal to generate powerful, consistent negative pressure with minimal heat and noise. This design also ensures excellent air-liquid separation, protecting the pump from damage and extending service life — making it ideal for multi-chair, high-volume practices.
        How do I know which model is right for my clinic?
        Please refer to our Selection Guide above. The two most critical factors are:
        - Simultaneous chair usage (not just total chairs)
        - Available electrical supply (voltage and phase)
        If you're unsure, simply send us a photo of your current unit's nameplate and installation area — our team will do the assessment for you.
        Can I install the TPC Superb Vac myself, or do I need a professional installer?
        While the unit itself is designed for straightforward setup, we strongly recommend that installation be performed by a licensed plumber and electrician familiar with dental equipment. Proper electrical connection, water supply, drain routing, and vacuum piping are critical for safe and optimal performance.
        What utilities do I need to have ready at the installation site?
        You will need:
        - Electrical: A dedicated circuit matching the unit's voltage and phase requirements.
        - Water supply: A potable water line with adequate flow and pressure.
        - Drain: A floor drain or suitable wastewater line for pump discharge.
        I don't know the technical details of my current setup. What should I do?
        Don't worry — we've got you covered. Simply take a few clear photos of:
        - The front and side of the current vacuum unit
        - The nameplate/rating label on the unit
        - The surrounding installation area (showing pipes, wiring, and drain)
        Then email them to our support team. We will review everything and get back to you with a precise recommendation — no technical background required on your end.
        Can I use my existing vacuum piping with the TPC Superb Vac?
        In many cases, yes. If your existing piping is properly sized and in good condition, it can often be reused. However, our team will need to review your setup (photos are helpful here) to confirm compatibility and ensure optimal suction performance.
        Is there any maintenance required for the TPC Superb Vac?
        Yes, but minimal. Routine maintenance includes:
        - Periodically checking and cleaning the water strainer
        - Inspecting water and drain connections for leaks
        - Changing the pump oil (if applicable) or following the wet ring service schedule as outlined in the manual
        Our product manual includes a detailed maintenance checklist to keep your system running smoothly for years.
        What warranty does the TPC Superb Vac come with?
        The TPC Superb Vac series is backed by a comprehensive warranty covering manufacturing defects and pump components. For specific warranty terms and duration, please refer to the product documentation or contact our sales team directly.
        How long does shipping take, and do you deliver to my area?
        We ship to all US locations. Once we confirm your ZIP code and model selection, we will provide an estimated delivery timeline. Standard transit times vary by distance, we will keep you informed with real-time shipping updates.
        I'm still not sure which model to choose — can you help?
        Absolutely! That's exactly why we ask for the information listed in our Selection Guide. Just reply with:
        - Number of chairs and simultaneous usage
        - Voltage and phase
        - Photos of your current unit and installation area
        Our technical team will personally review your setup and recommend the best TPC Superb Vac model for your practice — often within one business day.
